Eaton EMCH332 Memshield 3 TP Type C MCB 32A 10/15kA

Eaton MEM Memshield3 EMCH332 32A Triple Pole MCB has a short circuit breaking capacity of 10kA to IEC 60898 and 15kA to IEC 60947-2. The MCBs detect overcurrents due to both overload and fault currents. The MCB will operate and interrupt the supply to prevent damage. The MCBs has a positive indication for On or Off and the operating dolly may be locked in either the ON or OFF position without affecting the ability of the trip mechanism to operate. These MCB's are designed specifically for the Memshield 3 distribution boards.
  • Rating: 32 Amp
  • Poles: Triple pole
  • Trip curve: Type C
  • Number of modules: Three
  • Breaking Capacity: Dual rated 10kA (IEC 60898) 15kA (IEC 60947-2)
  • Voltage: 230/240 Volt AC
  • Terminal capacity: 25mm2
  • Height: 80mm
  • Width: 54mm
  • Depth: 60mm
  • Standards: EN/IEC 60947-2 EN/IEC 60898
Stock available Next working day
SKU
EATON-EMCH332
£52.83 £63.40
