Hager JG32BM 125A IP31 18 kA Triple Pole & Neutral Enclosed MCCB

Be the first to review this product

Hager JG32BM MCCB TPN Enclosed 125A 18kA

This product is subject to additional delivery costs due to its weight/size. Find out more

The devices are mounted in IP31 enclosures, with removable cable entry plates located on the top and bottom
Single & triple pole devices are equipped with fully rated neutral links
Triple pole: 125A - 250A - 400A - 630A
Conforms to BS EN 61439-2
63 - 125A: Flexible cable: min 6mm², max 70mm², Rigid cable: min 6mm², max 95mm²
RCD add-on adjustable from 0.03A, 0.1A, 0.3A, 1A, 3A, 6A.
Time delay - Instantaneous, 60ms, 150ms, 300ms, 500ms, 1s.

Estimated delivery 3-5 Working days

SKU

HG-JG32BM

£553.73 £664.48

Product Downloads

HG-JG32BM Catalog Page

HG-JG32BM Technical Data

Product Categories

Enclosed MCCBs

More Information

Hager JG32BM MCCB TPN Enclosed 125A 18kA

More Information
SKU	HG-JG32BM
Manufacturer Part Code	JG32BM
Product Range	Commercial
Mounting Method	Backplate
Ingress Protection	IP31
Depth (mm)	106.00 mm
Width (mm)	200.00 mm
Height (mm)	420.00 mm
Current Rating	125A
Short Circuit Rating	18 kA
Pole Configuration	4P
Cable Capacity	95 mm2
Voltage	400V
Standards	IEC60947-2
Is on Sale	No

Brand	Commercial
Circuit Breakers \| Description \| Product	MCCB
Circuit Breakers \| Description \| Product Type	TPN Enclosed IP31
Circuit Breakers \| Description \| Product	Circuit Breaker
Circuit Breakers \| Dimensions \| Depth (EF008810)	106 mm
Circuit Breakers \| Dimensions \| Height (EF008809)	420 mm
Circuit Breakers \| Features \| Ingress Protection (EF005474)	IP31
Circuit Breakers \| Features \| Mounting (EF000003)	Backplate
Circuit Breakers \| Features \| Pole Configuration	Four Pole (4P)
Circuit Breakers \| Features \| Short Circuit Rating	18 kA
Circuit Breakers \| General \| Standards	IEC60947-2
Circuit Breakers \| Technical Data \| Current Rating (EF000227)	125 A
Circuit Breakers \| Technical Data \| Voltage	400 V
