Integral ILCTCAS-PD200CB Constant Voltage Driver Casambi Primary Unit 200W IP20 48VDC Output Power-Line Control
For areas inaccessible by Bluetooth signal, use our combination of Primary and Secondary application drivers to allow full connectivity.
This Primary driver provides 48VDC output along with Casambi-to-power-line communication for connecting single colour or CCT-tunable Secondary drivers into a local hard-wired network, operated from one power supply.
The constant current adjustment, gradient speed, current trim level, zoning & grouping features are adjustable from the Casambi app and the Primary driver will transfer the commands to connected Secondary drivers via the power cable based on "Power-On" status detection.
- Input Voltage: 100-240VAC
- Output Power: 200W
- Output Voltage: 48VDC with PLC data
- Short Circuit / Over Load / Over Heat Protection
- Wireless Band: 2.4GHz ISM
- Used in conjunction with ILCTCAS-SDF20-S Secondary driver(s)
- Class I
For areas inaccessible by Bluetooth signal, use our combination of Primary and Secondary application drivers to allow full connectivity.
This Primary driver provides 48VDC output along with Casambi-to-power-line communication for connecting single colour or CCT-tunable Secondary drivers into a local hard-wired network, operated from one power supply.
The constant current adjustment, gradient speed, current trim level, zoning & grouping features are adjustable from the Casambi app and the Primary driver will transfer the commands to connected Secondary drivers via the power cable based on "Power-On" status detection.
| SKU | INLED-ILCTCAS-PD200CB |
|---|---|
| Manufacturer Part Code | ILCTCAS-PD200CB |
| Is on Sale | No |
