Click MiniGrid MD9001 6A 2 Way Push On/Off (Non-Dimming) Module
6A 2 Way Push On/Off (Non-Dimming) Module (25 x 62mm)
- Facilitates 1 way or 2 way switching
- Push 'On/Off' facility only
- Non-dimmable
- Not suitable for mounting above each other on multi-tier plates
Stock available Next working day
SKU
SCOL-MD9001
£8.68 £10.42
Product Categories
6A 2 Way Push On/Off (Non-Dimming) Module (25 x 62mm)
| SKU | SCOL-MD9001 |
|---|---|
| Manufacturer Part Code | MD9001 |
| Warranty | 1 Years |
| Product Range | Minigrid |
| Current Rating | 6A |
| Voltage | 230V |
| Material | Nylon |
| Mounting Method | Grid |
| Depth (mm) | 23.20 mm |
| Width (mm) | 25.50 mm |
| Height (mm) | 67.00 mm |
| Length (mm) | 65.00 mm |
| Back Box Depth (mm) | 25 |
| Switched | Unswitched |
| Number of ways | 2 |
| Pole Configuration | 1P |
| Ingress Protection | IP20 |
| Qualifier | Dimmer Modules |
| CE Approved | No |
| Standards | BS EN 60669-1 |
| Lockable | No |
| Is on Sale | No |
| Brand | Minigrid | |
| Wiring Accessories | Description | Product | Dimmer Switch | |
| Wiring Accessories | Description | Product Type | Non Dimming Push/Push Module | |
| Wiring Accessories | Description | Product | Switch Module | |
| Wiring Accessories | Description | Qualifier | Dimmer Modules MG | |
| Wiring Accessories | Description | Switched/Unswitched | Unswitched | |
| Wiring Accessories | Dimensions | Depth (EF008810) | 25 mm | |
| Wiring Accessories | Dimensions | Height (EF008809) | 67 mm | |
| Wiring Accessories | Dimensions | Length (EF004265) | 65 mm | |
| Wiring Accessories | Dimensions | Mounting Box Minimum Depth | 25 mm | |
| Wiring Accessories | Dimensions | Width (EF008808) | 25.5 mm | |
| Wiring Accessories | Features | FM/DAB | N | |
| Wiring Accessories | Features | Flex Outlet | N | |
| Wiring Accessories | Features | Fuse Fitted | N | |
| Wiring Accessories | Features | Includes 13A Switch Socket? | N | |
| Wiring Accessories | Features | Includes RCD? | N | |
| Wiring Accessories | Features | Ingress Protection (EF005474) | IP20 | |
| Wiring Accessories | Features | Lockable? | N | |
| Wiring Accessories | Features | Pole Configuration | Single Pole (1P) | |
| Wiring Accessories | Features | RJ11 | N | |
| Wiring Accessories | Features | RJ45 Cat 5E | N | |
| Wiring Accessories | Features | RJ45 Cat 6 | N | |
| Wiring Accessories | Features | Satellite | N | |
| Wiring Accessories | Features | Screwless? | N | |
| Wiring Accessories | Features | TV Socket | N | |
| Wiring Accessories | Features | Telephone Master | N | |
| Wiring Accessories | Features | Telephone Secondary | N | |
| Wiring Accessories | Features | USB | N | |
| Wiring Accessories | General | CE Approved | N | |
| Wiring Accessories | General | Warranty | 1 Years | |
| Wiring Accessories | Material & Finish | Body Material | Nylon | |
| Wiring Accessories | Technical Data | Current Rating (EF000227) | 6 A | |
| Wiring Accessories | Technical Data | Voltage | 230 V |
